如何在IE浏览器播放RTSP或RTMP流(RTSP/RTMP OCX播放控件)
好多开发者一直苦恼于如何在IE浏览器环境下，构建低延迟的RTSP或RTMP播放，对于RTSP流来说，好多公司通常的做法是把RTSP转RTMP，然后分发到RTMP服务器，然后服务器转http-flv出来，浏览器直接播放http-flv流，亦或通过flash控件直接播放RTMP流，还有就是，转hls流出来，缺点是hls流延迟更大。
以上方案未尝不可，如果对播放体验和延迟要求更高，最简单的做法是直接在IE浏览器下加载activex控件。
大牛直播SDK在现有SDK的基础上，扩展了ocx控件，用于IE浏览器下的低延迟RTMP或RTSP播放，不谦虚的说，也可能是行业内功能支持和延迟最好的RTMP和RTSP播放器(支持RTMP/RTSP H.265(hevc)播放)。
页面展示
1. 功能齐全的单画面RTMP流或RTSP流播放：
2. 同时播放4路RTMP流或RTSP流画面：
本地播放和集成说明：
本地播放
DEMO说明
- 1_player_ocx.html：单个窗口功能展示。
- 4_player_ocx.html：4窗口功能展示。
- SmartPlayer.exe：cs架构播放器。
运行网页播放端之前，请确保以管理员权限注册ocx控件：regplayerocx.bat右键–>“以管理员身份运行(A)”，同理，反注册也是需要管理员身份。
注意：大牛直播RTSP/RTMP播放OCX控件只适用于微软IE浏览器。
对应封装接口
ULONG NT_SetLogPath();
ULONG NT_Open();
ULONG NT_Close();
ULONG NT_StartPlay();
ULONG NT_StopPlay();
ULONG NT_SetMute(LONG is_mute);
ULONG NT_SetURL(LPCTSTR url);
ULONG NT_SetBuffer(LONG buffer);
ULONG NT_SetRTSPTcpMode(LONG isUsingTCP);
ULONG NT_SetRtspTimeout(LONG timeout);
ULONG NT_SetRtspAutoSwitchTcpUdp(LONG is_auto_switch_tcp_udp);
ULONG NT_SetFastStartup(LONG isFastStartup);
ULONG NT_SetLowLatencyMode(LONG mode);
ULONG NT_SetFlipVertical(LONG is_flip);
ULONG NT_SetFlipHorizontal(LONG is_flip);
ULONG NT_SetRotation(LONG degress);
ULONG NT_SwitchURL(LPCTSTR url);
ULONG NT_SetCaptureImagePath(LPCTSTR path);
ULONG NT_CaptureImage();
ULONG NT_SetRecorderDirectory(LPCTSTR dir);
ULONG NT_SetRecorderFileMaxSize(ULONG size);
ULONG NT_NT_SP_RecorderFileNameRuler(ULONG type, LPCTSTR file_name_prefix, LONG append_date, LONG append_time);
ULONG NT_SetRecorderAudioTranscodeAAC(LONG is_transcode);
ULONG NT_SetRecorderVideo(LONG is_record_video);
ULONG NT_SetRecorderAudio(LONG is_record_audio);
ULONG NT_StartRecorder();
ULONG NT_StopRecorder();
ULONG NT_FullScreen();
void OnSDKEventReceived(ULONG event_id, ULONG param1);
void OnVideoSizeReceived(ULONG width, ULONG height);
设置LOG存放路径：
ULONG CSmartPlayerActiveXCtrl::NT_SetLogPath(LPCTSTR log_path)
请于NT_Open() 之前调用，代码示例：
var obj = document.getElementById("SmartPlayerActiveX");
//如需记录log文件，请确保log路径存在, 如多级目录, 可按照"D:\\Daniulive\\log"类似格式设定, 记录文件名: smart_sdk.log
obj.NT_SetLogPath("D:\\");
接口说明：
1. ULONG NT_Open();
打开player实例；
2. ULONG NT_Close();
关闭player实例；
3. ULONG NT_StartPlay();
开始播放；
4. ULONG NT_StopPlay();
停止播放；
5. ULONG NT_SetMute(LONG is_mute);
设置实时静音；
6. ULONG NT_SetURL(LPCTSTR url);
设置播放的RTMP或RTSP url；
7. ULONG NT_SetBuffer(LONG buffer);
设置buffer time，缓冲时间，单位：毫秒；
8. ULONG NT_SetRTSPTcpMode(LONG isUsingTCP);
设置RTSP TCP/UDP播放模式；
9. ULONG NT_SetRtspTimeout(LONG timeout);
设置RTSP超时时间；
10. ULONG NT_SetRtspAutoSwitchTcpUdp(LONG is_auto_switch_tcp_udp);
设置是否自动切换TCP/UDP模式；
11. ULONG NT_SetFastStartup(LONG isFastStartup);
设置是否快速启动；
12. ULONG NT_SetLowLatencyMode(LONG mode);
设置是否低延迟模式播放；
13. ULONG NT_SetFlipVertical(LONG is_flip);
设置垂直反转模式图像；
14. ULONG NT_SetFlipHorizontal(LONG is_flip);
设置水平反转图像；
15. ULONG NT_SetRotation(LONG degress);
设置旋转图像，可设定角度：0度 90度 180度 270度；
16. ULONG NT_SwitchURL(LPCTSTR url);
设置快速切换RTSP/RTMP url；
17. ULONG NT_SetCaptureImagePath(LPCTSTR path);
设置快照保存位置；
18. ULONG NT_CaptureImage();
设置实时快照功能；
19. ULONG NT_SetRecorderDirectory(LPCTSTR dir);
设置录像保存位置；
20. ULONG NT_SetRecorderFileMaxSize(ULONG size);
设置单个录像文件最大size，单位：兆；
21. ULONG NT_NT_SP_RecorderFileNameRuler(ULONG type, LPCTSTR file_name_prefix, LONG append_date, LONG append_time);
设置录像文件命名规则：是否需要前缀、是否添加日期、是否添加时间；
22. ULONG NT_SetRecorderAudioTranscodeAAC(LONG is_transcode);
设置录像音频文件是否转AAC后录制，支持PCMA/PCMU/SPEEX转AAC后录制文件；
23. ULONG NT_SetRecorderVideo(LONG is_record_video);
设置是否录制视频；
24. ULONG NT_SetRecorderAudio(LONG is_record_audio);
设置是否录制音频；
25. ULONG NT_StartRecorder();
开始录像；
26. ULONG NT_StopRecorder();
停止录像；
27. ULONG NT_FullScreen();
全屏显示窗口。
事件Event：
1. void OnSDKEventReceived(ULONG event_id, ULONG param1);
回调网络状态、buffering状态、下载速度等；
事件类型：
<script>
var NT_EVENT_ID_SMART_PLAYER_SDK = 0x01000000;
var NT_SP_E_EVENT_ID_BASE = NT_EVENT_ID_SMART_PLAYER_SDK;
var NT_SP_E_EVENT_ID_CONNECTING = NT_SP_E_EVENT_ID_BASE | 0x2; /*连接中*/
var NT_SP_E_EVENT_ID_CONNECTION_FAILED = NT_SP_E_EVENT_ID_BASE | 0x3; /*连接失败*/
var NT_SP_E_EVENT_ID_CONNECTED = NT_SP_E_EVENT_ID_BASE | 0x4; /*已连接*/
var NT_SP_E_EVENT_ID_DISCONNECTED = NT_SP_E_EVENT_ID_BASE | 0x5; /*断开连接*/
var NT_SP_E_EVENT_ID_NO_MEDIADATA_RECEIVED = NT_SP_E_EVENT_ID_BASE | 0x8; /*收不到RTMP数据*/
var NT_SP_E_EVENT_ID_RTSP_STATUS_CODE = NT_SP_E_EVENT_ID_BASE | 0xB; /*rtsp status code上报, 目前只上报401, param1表示status code*/
/* 接下来请从0x81开始*/
var NT_SP_E_EVENT_ID_START_BUFFERING = NT_SP_E_EVENT_ID_BASE | 0x81; /*开始缓冲*/
var NT_SP_E_EVENT_ID_BUFFERING = NT_SP_E_EVENT_ID_BASE | 0x82; /*缓冲中, param1 表示百分比进度*/
var NT_SP_E_EVENT_ID_STOP_BUFFERING = NT_SP_E_EVENT_ID_BASE | 0x83; /*停止缓冲*/
var NT_SP_E_EVENT_ID_DOWNLOAD_SPEED = NT_SP_E_EVENT_ID_BASE | 0x91; /*下载速度， param1表示下载速度，单位是(Byte/s)*/
var NT_SP_E_EVENT_ID_PLAYBACK_REACH_EOS = NT_SP_E_EVENT_ID_BASE | 0xa1; /*播放结束, 直播流没有这个事件，点播流才有*/
var NT_SP_E_EVENT_ID_RECORDER_REACH_EOS = NT_SP_E_EVENT_ID_BASE | 0xa2; /*录像结束, 直播流没有这个事件, 点播流才有*/
var NT_SP_E_EVENT_ID_PULLSTREAM_REACH_EOS = NT_SP_E_EVENT_ID_BASE | 0xa3; /*拉流结束, 直播流没有这个事件，点播流才有*/
var NT_SP_E_EVENT_ID_DURATION = NT_SP_E_EVENT_ID_BASE | 0xa8; /*视频时长，如果是直播，则不上报，如果是点播的话, 若能从视频源获取视频时长的话，则上报， param1表示视频时长，单位是毫秒(ms)*/
</script>
调用展示：
<script language='javascript' for="SmartPlayerActiveX" event="OnSDKEventReceived(event_id, param1)">
// Test 1 - statically load the script (This is the basis for the hack)
// Works on IE8, IE9, IE10 and IE11
var show_str = "";
var connection_status = event_id;
if (connection_status != 0)
{
show_str += "链接状态: ";
if (NT_SP_E_EVENT_ID_CONNECTING == connection_status)
{
show_str += "链接中";
}
else if (NT_SP_E_EVENT_ID_CONNECTION_FAILED == connection_status)
{
show_str += "链接失败";
}
else if (NT_SP_E_EVENT_ID_CONNECTED == connection_status)
{
show_str += "链接成功";
}
else if (NT_SP_E_EVENT_ID_DISCONNECTED == connection_status)
{
show_str += "链接断开";
}
else if (NT_SP_E_EVENT_ID_NO_MEDIADATA_RECEIVED == connection_status)
{
show_str += "收不到数据";
}
}
var download_speed = -1;
if (NT_SP_E_EVENT_ID_DOWNLOAD_SPEED == event_id)
{
download_speed = param1;
}
if (download_speed != -1)
{
show_str += "下载速度:" + (download_speed * 8 / 1000).toFixed(0) + "kbps " + (download_speed / 1024).toFixed(0) + "KB/s";
}
var buffer_status = 0;
if (NT_SP_E_EVENT_ID_START_BUFFERING == event_id
|| NT_SP_E_EVENT_ID_BUFFERING == event_id
|| NT_SP_E_EVENT_ID_STOP_BUFFERING == event_id)
{
buffer_status = event_id;
}
if (buffer_status != 0)
{
show_str += "缓冲状态: ";
if (NT_SP_E_EVENT_ID_START_BUFFERING == buffer_status)
{
show_str += "开始缓冲";
}
else if (NT_SP_E_EVENT_ID_BUFFERING == buffer_status)
{
show_str += "缓冲中" + param1 + "%";
}
else if (NT_SP_E_EVENT_ID_STOP_BUFFERING == buffer_status)
{
show_str += "结束缓冲";
}
}
var EventMsgText = document.getElementById("EventMsg");
EventMsgText.innerHTML = show_str;
</script>
2. void OnVideoSizeReceived(ULONG width, ULONG height);
回调视频宽高信息。
调用展示：
<script language='javascript' for="SmartPlayerActiveX" event="OnVideoSizeReceived(width, height)">
// Test 1 - statically load the script (This is the basis for the hack)
// Works on IE8, IE9, IE10 and IE11
var VideoResolutionText = document.getElementById("VideoResolution");
VideoResolutionText.innerHTML = width + "*" + height;
</script>
SDK接口调用实例：
播放和录像调用示例：
var is_player_opened = false;
var is_playing = false;
var is_recording = false;
function OpenPlayer()
{
if(is_player_opened)
{
return;
}
var obj = document.getElementById("SmartPlayerActiveX");
//如需记录log文件，请确保log路径存在, 如多级目录, 可按照"D:\\Daniulive\\log"类似格式设定, 记录文件名: smart_sdk.log
obj.NT_SetLogPath("D:\\");
var ret = obj.NT_Open();
if(ret == 0)
{
//设置TCP/UDP模式
var rtsp_tcp_mode = document.getElementById("rtspTcpMode").checked ? 1 : 0;
obj.NT_SetRTSPTcpMode(rtsp_tcp_mode);
//设置RTSP超时时间
var rtsp_timeout = document.getElementById("rtspTimeout").value;
obj.NT_SetRtspTimeout(rtsp_timeout);
//设置是否自动切换TCP-UDP模式
var rtsp_auto_switch_tcp_udp = document.getElementById("rtspAutoSwitchTcpUdp").checked ? 1 : 0;
obj.NT_SetRtspAutoSwitchTcpUdp(rtsp_auto_switch_tcp_udp);
//设置是否快速启动
var fast_startup_mode = document.getElementById("fastStartupMode").checked ? 1 : 0;
obj.NT_SetFastStartup(fast_startup_mode);
//设置需要播放或录像的RTSP/RTMP url
var url = document.getElementById("playorReocordUrl").value;
obj.NT_SetURL(url);
//设置实时截图路径(可自行设置或选取系统存在的文件夹), 如多级目录可按照"D:\\Daniulive\\image"类似格式设定
//var image_path = "D:\\";
obj.NT_SetCaptureImagePath(image_path);
is_player_opened = true;
}
}
function ClosePlayer()
{
if(is_player_opened)
{
var obj = document.getElementById("SmartPlayerActiveX");
obj.NT_Close();
var EventMsgText = document.getElementById("EventMsg");
EventMsgText.innerHTML = "";
is_player_opened = false;
}
}
function OnBnClickedPlay()
{
if(!isIE())
{
alert("非IE浏览器，请用IE打开播放控件..");
return;
}
if(!isActiveXInstalled())
{
alert("控件未加载，请先加载控件..");
return;
}
if(is_playing)
{
StopPlayback();
}
else
{
StartPlayback();
}
}
//开始播放
function StartPlayback() {
if(!is_playing && !is_recording)
{
OpenPlayer();
}
var obj = document.getElementById("SmartPlayerActiveX");
//设置是否启用低延迟模式
var low_latency_mode = document.getElementById("lowlatencyMode").checked ? 1 : 0;
obj.NT_SetLowLatencyMode(low_latency_mode);
//设置缓冲时间
var buffer_time = document.getElementById("bufferTime").value;
obj.NT_SetBuffer(buffer_time);
var ret = obj.NT_StartPlay();
if(ret == 0)
{
is_playing = true;
var playBtnText = document.getElementById("playBtn");
playBtnText.innerHTML = "停止播放";
}
}
//停止播放
function StopPlayback() {
if(!is_playing)
{
return;
}
var obj = document.getElementById("SmartPlayerActiveX");
obj.NT_StopPlay();
is_playing = false;
var playBtnText = document.getElementById("playBtn");
playBtnText.innerHTML = "开始播放";
if(!is_recording)
{
ClosePlayer();
}
var VideoResolutionText = document.getElementById("VideoResolution");
VideoResolutionText.innerHTML = "";
}
function OnBnClickedRecord()
{
if(!isIE())
{
alert("非IE浏览器，请用IE打开播放控件..");
return;
}
if(!isActiveXInstalled())
{
alert("控件未加载，请先加载控件..");
return;
}
if(is_recording)
{
StopRecorder();
}
else
{
StartRecorder();
}
}
//开始录像
function StartRecorder() {
if(!is_playing && !is_recording)
{
OpenPlayer();
}
var obj = document.getElementById("SmartPlayerActiveX");
//设置实时录像存放路径(可自行设置或选取系统存在的文件夹), 如多级目录可按照"D:\\Daniulive\\rec"类似格式设定
var rec_dir = "D:\\";
obj.NT_SetRecorderDirectory(rec_dir);
var rec_max_size = 200;
obj.NT_SetRecorderFileMaxSize(rec_max_size);
var type = 0;
var file_name_prefix = "daniulive";
var append_date = 1;
var append_time = 1;
obj.NT_NT_SP_RecorderFileNameRuler(type, file_name_prefix, append_date, append_time);
var is_transcode = 1;
obj.NT_SetRecorderAudioTranscodeAAC(is_transcode);
var is_record_video = 1;
obj.NT_SetRecorderVideo(is_record_video);
var is_record_audio = 1;
obj.NT_SetRecorderAudio(is_record_audio);
var ret = obj.NT_StartRecorder();
if(ret == 0)
{
is_recording = true;
var recordBtnText = document.getElementById("recordBtn");
recordBtnText.innerHTML = "停止录像";
}
}
//停止录像
function StopRecorder() {
if(!is_recording)
{
return;
}
var obj = document.getElementById("SmartPlayerActiveX");
obj.NT_StopRecorder();
is_recording = false;
var recordBtnText = document.getElementById("recordBtn");
recordBtnText.innerHTML = "开始录像";
if(!is_playing)
{
ClosePlayer();
}
}
快速切换URL调用示例：
//快速切换播放URL
function SwitchUrl() {
if(!is_playing)
{
return;
}
var obj = document.getElementById("SmartPlayerActiveX");
var switch_url = document.getElementById("playorReocordUrl").value;
obj.NT_SwitchURL(switch_url);
}
实时静音调用示例：
//实时静音
var is_mute = 1;
function SetMute() {
var obj = document.getElementById("SmartPlayerActiveX");
obj.NT_SetMute(is_mute);
var muteText = document.getElementById("MuteBtn");
if(is_mute == 1 )
{
is_mute = 0;
muteText.innerHTML = "取消静音";
}
else
{
is_mute = 1;
muteText.innerHTML = "实时静音";
}
}
视频view垂直反转、水平反转、旋转调用示例：
//垂直反转
var is_flip_vertical = 1;
function SetFlipVertical() {
var obj = document.getElementById("SmartPlayerActiveX");
obj.NT_SetFlipVertical(is_flip_vertical);
var flipVerticalText = document.getElementById("FlipVerticalBtn");
if(is_flip_vertical == 1 )
{
is_flip_vertical = 0;
flipVerticalText.innerHTML = "取消反转";
}
else
{
is_flip_vertical = 1;
flipVerticalText.innerHTML = "垂直反转";
}
}
//水平反转
var is_flip_horizontal = 1;
function SetFlipHorizontal() {
var obj = document.getElementById("SmartPlayerActiveX");
obj.NT_SetFlipHorizontal(is_flip_horizontal);
var flipHorizontalText = document.getElementById("FlipHorizontalBtn");
if(is_flip_horizontal == 1 )
{
is_flip_horizontal = 0;
flipHorizontalText.innerHTML = "取消反转";
}
else
{
is_flip_horizontal = 1;
flipHorizontalText.innerHTML = "水平反转";
}
}
//视频view旋转
var rotate_degrees_ = 0;
function SetRotation() {
rotate_degrees_ += 90;
rotate_degrees_ = rotate_degrees_ % 360;
var obj = document.getElementById("SmartPlayerActiveX");
obj.NT_SetRotation(rotate_degrees_);
var rotateText = document.getElementById("RotateBtn");
if (0 == rotate_degrees_)
{
rotateText.innerHTML = "旋转90度";
}
else if (90 == rotate_degrees_)
{
rotateText.innerHTML = "旋转180度";
}
else if (180 == rotate_degrees_)
{
rotateText.innerHTML = "旋转270度";
}
else if (270 == rotate_degrees_)
{
rotateText.innerHTML = "不旋转";
}
}
实时截图调用示例：
function CaptureImage() {
var obj = document.getElementById("SmartPlayerActiveX");
obj.NT_CaptureImage();
}
全屏显示窗口调用示例：
//全屏显示窗口
function FullScreen() {
var obj = document.getElementById("SmartPlayerActiveX");
obj.NT_FullScreen();
}
相关资料和测试控件下载：
Github: https://github.com/daniulive/SmarterStreaming
QQ群：
